Appendix D: Default Configuration
Appendix D: Default Configuration
Table 1. Default Configuration
Reference
SP1
SP2
SP3
JP1
JP2
JP3
JP4
JP5
JP6
Name
CC02 mode
X2_44
X2_52
EA
MUTE
CANRes
RTS
DTR
Batt
Function
For T89C51CC02/T89C5115 usage, allow to redirect the
ISP signal to P1.0, for hardware conditions.
Connect PLCC44 Xtal2 to XTAL2 of the generic extension
board
Connect PLCC52 Xtal2 to XTAL2 of the generic extension
board
ON : allows external execution
OFF: Internal code execution
ON : Enable C51 generic extension board buzzer
OFF: Disable C51 generic extension board buzzer
ON : Enable CAN terminator resistor
OFF: Disable CAN terminator resistor
ON : Enable RTS line to control ISP mode
OFF: Disable RTS line to control ISP mode
ON : Enable DTR line to drive MCU reset
OFF: Disable DTR line to drive MCU reset
ON : Enable Battery charge
OFF: Disable Battery charge
State
Open
Open
Open
Open (OFF)
Open (OFF)
Open (OFF)
Open (OFF)
Open (OFF)
Open (OFF)
AT89STK-06 Demo Board Software Demo Guide
4-19
4339C–CAN–07/05
